Specifications:

​

Drive units

• ScanSpeak 1” Revelator Ring Radiator Tweeter w/ phase plug

• Scanspeak 5” Revelator slit cone Bass/Mid

• Scanspeak 5” Revelator slit cone Bass



Cabinets

• Low noise floor multi layer construction, asymmetric bracing

• Constrained layer damping – cabinet, drivers, crossovers

• Artisan polyurethane paint finish – satin black, satin white – or:

• Tasmanian Blackwood veneer – hand oiled, satin finish

• Terminals - Cardas Solid Copper, Rhodium plated



Technical

• Typical in room response: <40Hz - 30kHz

• Sensitivity: 89dB/1m/2.83 volts

• Power handling (typical music programme): 200 watts

• Recommended amplifier 20W – 250W RMS

• Nominal Impedance: ~3 ohms (benign phase)

• Dimensions: 92cm H, 18cm W, 23.5 cm D (36” H x 7” W x 9.25” D)

• With Plinth: 96cm H, 27cm W, 30 cm D (38” H x 10.5” W x 12 ” D)

• Weight (per speaker): approx. 16 kg (35 lb)

• Architecture: 212 way for better integration through the critical mid-range

• Crossover: high order separate element with premium quality air core inductors, polypropylene capacitors and non inductive resistors – separate boards with point-to-point component connections for each driver yields lower noise and crosstalk

• DBL differential bass loading – bass and mid-bass drivers in separate enclosures, individually tuned for fast impulse response, minimum group (time) delay, and resistive impedance behaviour (easy to drive) – bass rolloff is more gradual than typical ported speakers, giving the impression of greater bass extension without “bloat” or “boom”



NOTE: Custom paint colours and timber finishes available to order - POA
